///Backup ring or hoop is deformed or worn after a seal change
Intensifier: high-pressure side
Backup ring or hoop is deformed or worn after a seal change
Bronze backup rings and hoops support the HP seal. Fast wear points to a guide problem.
Safety first: Switch off the pump, release all pressure (open the on/off valve or bleed-down valve) and lock out before you open any high-pressure part. Never put a hand or tool near a running jet.
1Check the causes, most likely first0 of 2 checked
01Worn plunger bearing or guideMost likely
The plunger runs off-centre and loads the backup ring.
How to check: Check the bearing and guide bushing.
General advice based on manufacturer manuals and service practice. Always follow the manual of your machine. Not sure? .
